CONFIGURATION INFORMATION

Configuration and Jumper Options

Pin Numbers refer to the Option Jumper Block)
SCSI ID Selection Up to sixteen devices (the host and fifteen targets) can be attached to the SCSI bus. These are selected with jumpers on Multi-Function Connector J2. In multiple-device systems, each device must have its own Unique SCSI ID. The SCSI ID (drive address) jumpers are identified as ID0, ID1, ID2, and ID3. ID selection is binary, as shown below.


	SCSI ID		ID3	ID2	ID1	ID0

	0 (Default)	out	out	out	out
	1		out	out	out	in
	2		out	out	in	out
	3		out	out	in	in
	4		out	in	out	out
	5		out	in	out	in
	6		out	in	in	out
	7		out	in	in	in
	8		in	out	out	out
	9		in	out	out	in
	10		in	out	in	out
	11		in	out	in	in
	12		in	in	out	out
	13		in	in	out	in
	14		in	in	in	out
	15		in	in	in	in

Interface Termination If terminators are installed at RN1, RN2, and RN3 (default), the drive provides termination for the SCSI interface. If the terminators are not installed, the drive does not provide interface termination. SCSI terminators are installed only in the end devices on the SCSI cable; remove the terminators from each of the other devices. The SCSI Host Adapter card and the last drive in the chain should have terminators.
Terminator Power W1 and W2 select the source of power (+5V) for the interface terminators; W3 controls the drive supplying +5V to the bus.

   W1    W2    W3

    Y     N     -     Drive provides terminator power. (Default)
    N     Y     -     Host provides terminator pwr via J1 pin 26
                          to RN1 and RN2

    -     -     Y     Drive supplies +5V to the bus via J1 pin 26.
                          (Default)

Remote LED A user-supplied LED may be connected to Remote LED (Pins 21 and 22).
Spindle Options Jumpers at SP0 (Pins 9 and 10) and SP1 (Pins 11 and 12) control the spindle options.

	SP0	SP1

	 N	 N	The drive starts the spindle motor at power-on.
			   (Default)
	 Y	 N	The drive waits for a Start Unit SCSI command
			   to start the spindle motor.
	 N	 Y	Spindle start-up is delayed based on SCSI ID
			   address (12 seconds per ID)

Write Protect A jumper at WRP (Pins 13 and 14) selects the write protect option.

	Jumper		The drive is write protected.
	No Jumper	The drive is not write protected. (Default)

Parity A jumper at PAR (Pins 15 and 16) selects the bus parity check option. The drive always generates parity regardless of this option.

	Jumper		SCSI interface parity checking disabled.
	No Jumper	SCSI interface parity checking on. (Default)

Spindle Sync Signals Use of the MS and SS signals is optional. These signals are used as spindle synchronization reference.
